UFI EPB12NFC Replaces the Sofima CCH152FD1

UFI EPB12NFC
UFI EPB12NFC

UFI EPB12NFC Replaces the Sofima CCH152FD1

EPB12NFC
UFI
Sofima CCH152FD1
Description

Original UFI EPB12NFC replacement filter.

Brand: UFI
Sort by:
Price Matched
Ships in 58 Days
$33.00
Price$33.00/each
Shipped Tuesday, 3 June
 Order within 10hrs 32mins
UNITSPER UNIT
2 - 4$32.34
5 - 9$31.68
10+$31.02
8421.99.90
Italy
Shipping Terms

Description

Original UFI EPB12NFC replacement filter.

Specification

StylePressure Filter
Efficiency 110µ @ β200
Efficiency 212µ @ β1000
Outer Diameter 45.0 mm
Inner Diameter 25.5 mm
Length 112.0 mm
MediaGlass Fiber
Flow DirectionOUT-IN
Δ Collapse Pressure 21 BAR
Seal MaterialNitrile
Temperature Range -30 - +100°C

Approved Product

Find out more
Sofima Brand Logo

Same Fit-Form & Function

As the Genuine Sofima CCH152FD1

ISO Icon

Inspected to ISO 9001:2015

See Our Certification
Returns Icon

Free 45-Day Returns

Return Policy
Warranty Icon

1 Year Manufacturer Warranty

Our Warranty
Specification
Efficiency 1
The efficiency of the element is shown using the Micron (µ) and Beta (β) ratings. The micron rating indicates the size of the particle being filtered and the beta rating the efficiency, calculated as 1/β.
E.g. a rating of β200 will be 99.5% efficient whereas β1000 would be 99.9%.
10µ @ β200
Efficiency 2 12µ @ β1000
Style Pressure Filter
Outer Diameter 45.0 mm
Inner Diameter 25.5 mm
Length 112.0 mm
Media Type Glass Fiber
Flow Direction OUT-IN
Thread
Bypass Pressure

Bypass pressure relieve build-up of pressure within the system and allows medium to bypass the element when pressure increases and reaches a sufficient level.

Collapse Pressure 21 BAR
Seal Nitrile
Temperature Range -30 - +100°C
